3204A SKF Angular Contact Ball Bearings Sponsored Products Related To This Item

Fatigue limit load, Cu:0.51 kN
f0:13.8
Nlim (grease):11,000 rpm
Min operating temperature, Tmin:-25 °C
Max operating temperature, Tmax:110 °C
Characteristic cage frequency, FTF:0.4 Hz
Characteristic rolling element frequency, BSF:4.68 Hz
Characteristic outer ring frequency, BPF0:3.58 Hz
Characteristic inner ring frequency, BPFI:5.42 Hz
da min:35 mm
da max:39 mm
Da max:57 mm
ra max:1 mm
Category:Single Row Ball Bearing
Inventory:0.0
Minimum Buy Quantity:N/A
Product Group:B00308
Enclosure:2 Seals
Precision Class:ABEC 1 | ISO P0
Maximum Capacity / Filling Slot:No
Rolling Element:Ball Bearing
Snap Ring:No
Internal Special Features:No
Cage Material:Steel
Enclosure Type:Non-Contact Seal
Internal Clearance:C3-Loose
Inch - Metric:Metric
Long Description:30MM Bore; 62MM Outside Diameter; 16MM Outer Race Width; 2 Seals; Ball Bearing; ABEC 1 | ISO P0; No Filling Slot; No Snap Ring; No Internal Special Features; C3-Loose Internal Clearance; Steel Cage; N
Other Features:Deep Groove | Non-Friction Nitrile Rubber Seal | Prelubricated
UNSPSC:31171504
Harmonized Tariff Code:8482.10.50.68
Noun:Bearing
Keyword String:Ball
Weight / LBS:0.439
Bore:1.181 Inch | 30 Millimeter
Outer Race Width:0.63 Inch | 16 Millimeter
Inner Race Width:0 Inch | 0 Millimeter
Outside Diameter:2.441 Inch | 62 Millimeter
